Climax BB4500 - Igure B-10. Single Arm Mount Assembly (P;N 37472)

P/N 92974, Rev. 1 Page 93
F
IGURE B-10. SINGLE-ARM MOUNT ASSEMBLY (P/N 37472)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 1/2-13 X 2 SHCS
1403641
WASHER 1/2 FLTW HARDENED 1-1/8 OD X 3/16 THK17145
4
2
PLATE SPACER TACK WELD MTG1986913
WASHER 5/16 FLTW HARDENED217988
4
ASSY BRG SPHERICAL 2-1/4 ID W/ CLAMP COLLAR262481
5
BRACKET MTG SPHERICAL BRG 1-ARM2625116
SCREW 1/2-20 X 2 SSSFP
262524
7
SCREW 5/16-24 X 2 HHCS FLANGED BLK OX
4536448
2
5
1
7
4
4
8
6
3
