Climax BB4500 - Igure B-11. Double Arm Mount Assembly (P;N 37473)

Page 94 BB4500-BB5000 Operating Manual
FIGURE B-11. DOUBLE-ARM MOUNT ASSEMBLY (P/N 37473)
PARTS LIST
DESCRIPTION
P/N:
QTY
ITEM
SCREW 1/2-13 X 2 SHCS
1403681
WASHER 1/2 FLTW HARDENED 1-1/8 OD X 3/16 THK
1714582
PLATE SPACER TACK WELD MTG
1986923
WASHER 5/16 FLTW HARDENED
2179884
ASSY BRG SPHERICAL 2-1/4 ID W/ CLAMP COLLAR
262481
5
SCREW 1/2-20 X 2 SSSFP
2625246
MTG BRACKET SPHERICAL BRG 2-ARM
265171
7
SCREW 5/16-24 X 2 HHCS FLANGED BLK OX
4536448
5
3
6
8
4
4
7
2
1
2
1
