Small Bore Components for Your BB5000:
1-¼ inch diameter small bore kit includes the following:
48999 RDU sleeve with drive key, AFU sleeve 26719
(4) bearing sleeves
26263 set of aluminum set up cones
1-¼ inch diameter small bore kit includes the following:
48999 RDU drive sleeve with drive key, AFU sleeve
26719 (4) bearing sleeves
26263 set of aluminum set up cones
26656 1.25” alignment tool for BoreWelder
1-¾ inch diameter small bore kit includes:
49001 RDU sleeve with drive key & AFU sleeve
26722 (4) bearing sleeves
43383 Small cast iron set up cones for 1-¾ inch bar
1-¾ inch diameter small bore kit includes:
49001 RDU sleeve with drive key & AFU sleeve
26722 (4) bearing sleeves
43383 Small cast iron set up cones for 1-¾ inch bar
36082 1-¾ inch alignment tool for BoreWelder
Include rotational drive sleeve with drive key, axial feed sleeve, and two
bearing sleeves (every bearing requires a sleeve). All sleeves
include retaining snap rings.
1-¼ inch (31.8 mm) diameter small bore sleeve set
(for use with 2-¼ inch (57.2 mm) diameter components.
RDU sleeve with drive key, AFU sleeve, (2) bearing sleeves.
1-¼ inch (31.8 mm) diameter small bore sleeve set
(for use with 2 inch (50.8 mm) diameter components.)
RDU sleeve with drive key, AFU sleeve, (2) bearing sleeves
1-¾ inch (44.5 mm) diameter small bore sleeve set
(for use with 2- inch (57.2 mm) diameter components)
RDU sleeve with drive key, AFU sleeve, (2) bearing sleeves
Set of (2) aluminum set-up cones, 1.5 - 3.25 inch (38.1 -
82.6 mm) diameter,
Set of (2) cast iron set-up cones, 2.0 – 6.0 inch (50.8 – 152.4
mm) diameter,
(2) bearing sleeves
(2) bearing sleeves
snap rings for 2-¼ inch (57.2 mm) diameter components
Snap rings for 2 inch (50.8 mm) diameter components
RDU sleeve with key for 1-¼ inch diameter bar
RDU sleeve with key for 1-¾ inch diameter bar
RDU sleeve with key for 2 inch diameter bar
AFU sleeve with key for 1-¼ inch diameter bar
AFU sleeve with key for 1-¾ inch diameter bar
AFU sleeve with key for 2 inch diameter bar
8 Optional Small Bore Components
If selecting Small Bore components, please select from the following.
Bars selected separately. For additional options including complete small
bore kits and kits with bars, please refer to the page 13.
AFU & RDU Collets & Drive Key
Collets for 1-¼ inch bar (inch)
Collets for 1-¼ inch bar (metric)
Collets for 1-¾ inch bar (inch)
Collets for 1-¾ inch bar (metric)
1-¼ inch Boring Bar for Kit (inch)
36 inch bar,
3
/8 inch tooling holes every 6 inches
48 inch bar,
3
/8 inch tooling holes every 6 inches
72 inch bar,
3
/8 inch tooling holes every 6 inches
96 inch bar,
3
/8 inch tooling holes every 6 inches
48 inch bar,
3
/8 inch tooling holes every 10 inches
72 inch bar,
3
/8 inch tooling holes every 10 inches
96 inch bar,
3
/8 inch tooling holes every 10 inches
120 inch bar,
3
/8 inch tooling holes every 10 inches
144 inch bar,
3
/8 inch tooling holes every 10 inches
* Multiple units may be ordered.
1-¼ inch Boring Bar for Kit (metric)
914.4 mm bar, 10 mm tooling holes every 152.4 mm
1219.2 mm bar, 10 mm tooling holes every 152.4 mm
1828.8 mm bar, 10 mm tooling holes every 152.4 mm
2438.4 mm bar, 10 mm tooling holes every 152.4 mm
1219.2 mm bar, 10 mm tooling holes every 254.0 mm
1828.8 mm bar, 10 mm tooling holes every 254.0 mm
2438.4 mm bar, 10 mm tooling holes every 254.0 mm
3048.0 mm bar, 10 mm tooling holes every 254.0 mm
3657.6 mm bar, 10 mm tooling holes every 254.0 mm
* Multiple units may be ordered.
1-
3
/4 inch Boring Bar for Kit (inch)
36 inch bar, ½ inch tooling holes every 6 inches
48 inch bar, ½ inch tooling holes every 6 inches
60 inch bar, ½ inch tooling holes every 6 inches
72 inch bar, ½ inch tooling holes every 6 inches
96 inch bar, ½ inch tooling holes every 6 inches
48 inch bar, ½ inch tooling holes every 10 inches
60 inch bar, ½ inch tooling holes every 10 inches
72 inch bar, ½ inch tooling holes every 10 inches
96 inch bar, ½ inch tooling holes every 10 inches
120 inch bar, ½ inch tooling holes every 10 inches
144 inch bar, ½ inch tooling holes every 10 inches
* Multiple units may be ordered.
1-
3
/4 inch Boring Bar for Kit (metric)
914.4 mm bar, 12 mm tooling holes every 152.4 mm
1219.2 mm bar, 12 mm tooling holes every 152.4 mm
1524.0 mm bar, 12 mm tooling holes every 152.4 mm
1828.8 mm bar, 12 mm tooling holes every 152.4 mm
2438.4 mm bar, 12 mm tooling holes every 152.4 mm
1219.2 mm bar, 12 mm tooling holes every 254.0 mm
1828.8 mm bar, 12 mm tooling holes every 254.0 mm
1524.0 mm bar, 12 mm tooling holes every 254.0 mm
2438.4 mm bar, 12 mm tooling holes every 254.0 mm
3048.0 mm bar, 12 mm tooling holes every 254.0 mm
3657.6 mm bar, 12 mm tooling holes every 254.0 mm
* Multiple units may be ordered.
3
/8 inch Tooling Kits (for 1- inch bars)
HSS 0 degree and 15 degree lead angles (3 lengths)
0.98, 1.3 and 1.8 inches
HSS 15 degree lead angle (3 lengths)
1.3, 1.8 and 2.2 inches
Cemented carbide 0 and 15 degree lead angle
Cemented carbide 15 degree lead angle (3 lengths)
1.3, 1.8 and 2.2 inches
10 mm Tooling Kits
HSS 0 degree and 15 degree lead angles (3 lengths)
25, 33 and 46 mm
HSS 15 degree lead angle (3 lengths)
25, 33 and 46 mm
Small Bore Kit Bearing Collets
1-¼ inch (31.8 mm) bearing collet (each)
1-¾ inch (44.5 mm) bearing collet (each)
Small Bore Kit Setup Cones
For 1-½ to 3-¼ inch (38.1 to 82.6 mm) - aluminum
For 2 to 6 inches (50.8 to 152.4 mm) - cast iron
Configurations shown represent standard options. Please contact us for special fixturing, CNC Control options, or
other features that may be needed for your specific machining application. We look forward to working with you!
