Climer ACP06 - Page 36

ACP Air/Water heat pumps wih axial fans
36
TECHNICAL SPECIFICATIONS Unit
ACP
12 12T
Cooling
Cooling capacity (1)
kW 4,55 / 8,51 / 9,36* 4,55 / 8,51 / 9,36*
min/nom/max
Input power (1) kW 2,79 2,79
E.E.R. (1) W/W 3,05 3,05
Cooling capacity (2)
kW 6,41 / 11,6 / 12,8* 6,41 / 11,6 / 12,8*
min/nom/max
Input power (2) kW 2,79 2,79
E.E.R. (2) W/W 4,16 4,16
SEER (5) W/W 4,43 4,43
Water ow rate (1) L/s 0,41 0,41
User side heat exchanger pressure drops (1) kPa 8,8 8,8

Heang capacity (3)
kW 5,33 / 11,8 / 13,6* 5,33 / 11,8 / 13,6*
min/nom/max
Input power (3) kW 2,73 2,73
C.O.P. (3) W/W 4,32 4,32
Heang capacity (4)
kW 5,13 / 11,5 / 13,2* 5,13 / 11,5 / 13,2*
min/nom/max
Input power (4) kW 3,33 3,33
C.O.P. (4) W/W 3,44 3,44
SCOP (6) W/W 4,47 4,47
Water ow rate (4) L/s 0,55 0,55
User side heat exchanger pressure drops (4) kPa 13,1 13,1
Energy eciency
Classe A+++/A++ A+++/A++
water 35°C / 55°C

Type Twin Rotary DC Inverter
Number of compressors 1 1
Refrigerant oil (type) ESTER OIL VG74
Oil charge (amount) L 1 1
Refrigerant circuits 1 1

Type R32 R32
Refrigerant charge (7) kg 2,5 2,5
Amount of refrigerant in equivalent CO2 tonnes (7) ton 1,7 1,7
Design pressure (high/low) heat pump mode bar 42,8/1,3 42,8/1,3
Design pressure (high/low) chiller mode bar 42,8/3,5 42,8/3,5
Fans
Type DC Brushless Motor
Number 1 1
Intenal heat
exchanger
Internal heat exchanger type Plates
N° internal heat exchangers 1 1
Water content L 1,2 1,2
Water circuit
Useful head (1) kPa 63,4 63,4
Water content of hydronic circuit L 1,8 1,8
Maximum water side pressure bar 6 6
Plumbings ngs inch 1"M 1"M
Minimum water volume (8) L 60 60
Maximum circulator output kW 0,075 0,075
Maximum circulator absorbed current A 0,38 0,38
Energy Eciency Index (EEI) circulator ≤ 0,21 ≤ 0,21

Sound power level Lw (9) dB(A) 65 65
Sound power level Lw (10) dB(A) 62 62
Electrical data
Power supply 230V/1/50Hz 400V/3P+N+T/50Hz
Maximum input power kW 5,1 5,1
Maximum input current A 22,1 7,3
Maximum input power with anfreeze kit kW 5,2 5,2
Maximum input current with anfreeze kit A 22,7 7,5
