TECHNICAL SPECIFICATIONS Unit
ACP
14 14T
Cooling
Cooling capacity (1)
kW 6,87 / 11,5 / 12,1* 6,87 / 11,5 / 12,1*
min/nom/max
Input power (1) kW 3,53 3,53
E.E.R. (1) W/W 3,25 3,25
Cooling capacity (2)
kW 9,17 / 14,0 / 14,7* 9,17 / 14,0 / 14,7*
min/nom/max
Input power (2) kW 2,59 2,59
E.E.R. (2) W/W 5,40 5,40
SEER (5) W/W 4,77 4,77
Water ow rate (1) L/s 0,55 0,55
User side heat exchanger pressure drops (1) kPa 12,9 12,9

Heang capacity (3)
kW 7,54 / 14,1 / 15,2* 7,54 / 14,1 / 15,2*
min/nom/max
Input power(3) kW 2,91 2,91
C.O.P. (3) W/W 4,85 4,85
Heang capacity (4)
kW 7,23 / 13,6 / 14,6* 7,23 / 13,6 / 14,6*
min/nom/max
Input power (4) kW 3,55 3,55
C.O.P. (4) W/W 3,82 3,82
SCOP (6) W/W 4,48 4,48
Water ow rate (4) L/s 0,65 0,65
User side heat exchanger (4) kPa 13,0 13,0
Energy eciency
Classe A+++/A++ A+++/A++
water 35°C / 55°C

Type Twin Rotary DC Inverter
Number of compressors 1 1
Refrigerant oil (type) ESTER OIL VG74
Oil charge (amount) L 1,4 1,4
Refrigerant circuits 1 1

Type R32 R32
Refrigerant charge (7) kg 3,2 3,2
Amount of refrigerant in equivalent CO2 tonnes (7) ton 2,2 2,2
Design pressure (high/low) heat pump mode bar 42,8/1,3 42,8/1,3
Design pressure (high/low) chiller mode bar 42,8/3,5 42,8/3,5
Fans
Type DC Brushless Motor
Number 2 2
Internal heat
exchanger
Internal heat exchanger type Plates
N° internal heat exchangers 1 1
Water content L 1,7 1,7
Water circuit
Useful head (1) kPa 75,0 75,0
Water content of hydronic circuit L 3,0 3,0
Maximum water side pressure bar 6 6
Plumbing ngs inch 1"M 1"M
Minimum water volume (8) L 60 60
Maximum circulator output kW 0,14 0,14
Maximum circulator absorbed current A 1,10 1,10
Energy Eciency Index (EEI) cirulator ≤ 0,23 ≤ 0,23

Power sound level Lw (9) dB(A) 68 68
Power sound level Lw (10) dB(A) 66 66
Electrical data
Power supply 230V/1/50Hz 400V/3P+N+T/50Hz
Maximum input power kW 6,6 6,6
Maximum input current A 28,6 9,5
Maximum input power with anfreezre kit kW 6,7 6,7
Maximum input current with anfreeze kit A 29,2 9,7
