Page 14
5- OPERATION
CWS Basic 121-161-201-251
5.4 Fan coil in summer operation
(standard fan coil control panel)
The temperature in each cabin is controlled by a room thermostat, which controls
the fan motor. The panel (fan coil) "Mode" switch (see fig.1) must be set in "blue
ice star" position. Set the thermostat according to the desired temperature. From
the control panel, it is also possible to check the fan coil speed through the "speed
control" switch, as shown in fig.1.
The fan speed control can run the fan on three different speeds. The minimum
speed is in the centre of the fan control switch.
5.5 Fan coil in winter operation
(standard fan coil control panel)
The temperature in each cabin is controlled by a room thermostat, which controls
the fan motor. The panel (fan coil) "Mode" switch (see fig.1) must be set in "red sun"
position. Set the thermostat according to the desired temperature. From the control
panel, it is also possible to check the fan coil speed through the "speed control"
switch, as shown in fig.1.
The fan speed control can run the fan on three different speeds. The minimum
speed is in the centre of the fan control switch.
fig.1
