CWW
16
Внимание!
Задължително трябва да бъде монти-
ран предпазен ключ-поток (ако не е
фабрично инсталиран такъв, или ди-
ференциален пресостат). Това трябва
да бъде направено на права тръбна
секция на разстояние от изхода на
топлообменнкика не по-малко от 8-10
пъти диаметъра на тръбата. Ако това
не е изпълнено, гаранцията на изде-
лието незабавно и безусловно отпада.
5.2.2. Изпарител
Изключително важно е водата да вли-
за в машината през точката маркира-
на с табелка WATER INLET(входяща
вода).
За направа на водните връзки, в зависимост от
модела са използвани резбови или фланцеви
сглобки (моля, вижте схемите, на които са отбеля-
зани и позициите на връзките).
Изключително важно е водният кръг да
е свързан така, че потокът от вода към
топлообменника да е постоянен при
всякакви условия на работа. Промен-
лив воден поток е приемлив само ако
чилърът е оборудван с десуперхийтър
Тъй като необходимата охладителна мощност,
обикновено не съвпада с това, което се произвеж-
да от компресорите, те често работят с прекъсване.
В инсталации с малък воден обем, когато ефектът
на термичната инерция не се усеща толкова много,
системата трябва да бъда проверена, за да се уве-
рите, че е налице следната зависимост:
V > P/115n
където:
V = обем на водата (литри)
P = мощност (ватове)
n = брой на стъпките на компресорите.
Ако не е изпълнено това условие, трябва да бъде
инсталиран допълнителен буферен съд, който да
добави недостигащия воден обем към системата.
Този резервоар не трябва да има някакви специал-
ни характеристики. Достатъчно е да бъде изолиран
(както са изолирани тръбите за студена вода), така
че да не влияе върху работата на системата и да се
предотврати образуването на конденз.
Aenon!
A safety ow switch has to be installed
(if the ow switch/dierenal water
pressure switch are not already ed)
along a straight secon of piping at a
distance from the exchanger outlet of
not less than 8-10 mes the diameter of
the piping. The guarantee will immedi-
ately become null and void if the above
is not complied with.
5.2.2. Evaporator
It is vitally important that the water
enters the unit from the connection
point marked with the “WATER INLET”
plate.
Threaded or flanged male unions, depending on
the models, are used to make water connections
(please refer to the scale drawings which also show
the position of the unions).
It is vitally important to connect the
water circuit so that the flow of water to
the exchanger is always constant under
all operating conditions. A variable
flow of water is only accepted for the
desuperheaters contained in units
As the demand for cooling by utilities does not
generally coincide with what is delivered by the
compressors, they often work intermittently. In
units with a low water content, where the effect of
thermal inertia is not felt so much, the system should
be checked to make sure it satisfies the following
relation:
V > P/115n
where:
V = volume of water (litres)
P = power capacity of the unit (Watts)
n = number of capacity steps.
If the above volumes are not obtained, a storage tank
should be installed so as to satisfy the above relation
when added to the capacity of the system.
This tank requires no special features; it just needs
to be isolated, just like the chilled water pipes, so as
not to affect the performance of the system and to
prevent the formation of condensation.
