Clipper Marine Corp. CM21 - Page 33

CM-21
STANDING RIGGING-F/D
Wire Tnbkl
Shroud Dia. Size Length
Headstay 1/8x1x19 1/8 21’-8 1/2”
Backstay 1/8x1x19 1/8 26’-11”
Uppers 1/8x1x19 1/8 20’-10”
Lowers 1/8x1x19 1/8 10’-3”
SHEETS & MISC- RUNNING RIGGING
Sheets & Lines #ofLine Wire Sz Length Cleat
Main #10 5/16 32’ 4”-2 hole
Jib/Genoa #10 5/16 32’ 4”-2 hole
Spinnaker #12 3/8 36’ 4”-2 hole
Spin-foreguy #12 3/8 32’ 4”-2 hole
Downhaul #8 1/4 3’ 4”-2 hole
Outhaul #8 1/4 3’ 4”-2 hole
Traveler #8 1/4 3’ 4”-2 hole
STANDING RIGGING-CABIN
Wire Tnbkl
Shr
oud Dia. Size Length
Headstay 1/8x1x19 1/8 22’-4 1/4”
Backstay 1/8x1x19 1/8 27’-3”
Uppers 1/8x1x19 1/8 21’-11”
Lowers 1/8x1x19 1/8 11’-4”
HALYARD & MISC.
Wire Wire Line Line Block
Hal
yard Dia. Len Dia. Len Shackle Cleat
Jib 3/32” 19’-4” 5/16” 22’ 1/4” 4”-2 hole
Spinnaker 3/32” . 5/16” 56’ 1/4” 4”-2 hole
Pole Lift . . . 40’ 1/4” 4”-2 hole
Main 3/32” 22’-2 1/4” 5/16” 22’ 1/4” 4”-2 hole
