Clipper Marine Corp. CM21 - Page 34

CM-23
STANDING RIGGING-CABIN
Wire Tnbkl Line
Shroud Dia. Size Length
Headstay 1/8x1x19 1/8 26’-1/4”
Backstay 1/8x1x19 1/8 27’-11 3/4”
Uppers 1/8x1x19 1/8 24’-6”
Fwd Lowers 1/8x1x19 1/8 12’-1”
Aft Lowers 1/8x1x19 1/8 12’-2 1/2”
SHEETS & MISC- RUNNING RIGGING
Sheets & Lines #ofLine Wire Sz Length Blk Shackle Cleat
Main #12 3/8 52’ 1/4” 4”-2 hole
Jib/Genoa #12 3/8 52’ 1/4” 4”-2 hole
Spinnaker #12 3/8 36’ 1/4” 4”-2 hole
Spin-foreguy #12 3/8 36’ 1/4” 4”-2 hole
Downhaul #8 1/4 3’ 1/4” 4”-2 hole
Outhaul #8 1/4 3’ 1/4” 4”-2 hole
Traveler #8 1/4 3’ 1/4” 4”-2 hole
HALYARD & MISC.
Wire Wire Line Line Block
Hal
yard Dia. Len Dia. Len Shackle Cleat
Jib 3/32” 23’-1/2” 5/16” 28’ 1/4” 4”-2 hole
Spinnaker 3/32” . 5/16” . 1/4” 4”-2 hole
Pole Lift 3/32” . 5/16” . 1/4” 4”-2 hole
Main 3/32” 23’-1/2” 5/16” 28’ 1/4” 4”-2 hole
