Clipper Marine Corp. CM21 - Page 35

CM-26
STANDING RIGGING-F/D
Wire Tnbkl Line
Shroud Dia. Size Length
Headstay 1/8x1x19 1/8 27’-8”
Backstay 1/8x1x19 1/8 30’-7”
Uppers 1/8x1x19 1/8 25’-9”
Fwd Lowers 1/8x1x19 1/8 12’-6 1/2”
Aft Lowers 1/8x1x19 1/8 12’-8 1/4”
STANDING RIGGING-CABIN
Shroud Wire dia. Tnbkl Sz Line Length
Headstay 1/8x1x19 1/8 28’-3”
Backstay 1/8x1x19 1/8 30’-3 1/2”
Uppers 1/8x1x19 1/8 26’-8”
Fwd Lowers 1/8x1x19 1/8 13’-6”
Aft Lowers 1/8x1x19 1/8 13’-7 1/4”
SHEETS & MISC- RUNNING RIGGING
Sheets
& Lines #ofLine Wire Sz BlkShackle Cleat Length
Main #12 3/8 52’ 4”-2 hole 52’
Jib/Genoa #12 3/8 53’ 4”-2 hole 52’
Spinnaker #12 3/8 36’ 4”-2 hole 50’
Spin-foreguy #12 3/8 ??’ 4”-2 hole 36’
Downhaul #8 1/4 3’ 4”-2 hole 3’
Outhaul #8 1/4 3’ 4”-2 hole 3’
Traveler #8 1/4 3’ 4”-2 hole 3’
HALYARD & MISC.
Wire Wire Line Line Block
Halyard Dia. Len Dia. Len Shackle Cleat
Jib 3/32” 24’-11” 5/16” 28’ 1/4” 4”-2 hole
Spinnaker . . 5/16” 57’ 1/4” 4”-2 hole
Pole Lift . 5/16” 40’ 1/4” 4”-2 hole
Main 3/32” 25’-7 1/2” 5/16” 28’ 1/4” 4”-2 hole
Foreguy . . 3/8” 36’ 1/4” 4”-2 hole
