Clipper 100 - Blade Adjustment and Maintenance

Unscrew
Adjusting Blade:
Each blade has eight (8) cutting surfaces. When
thebladebecomesdull,rotatetonextnewcutting
surface as follows:
1. With the Slide Arm fully retracted into the
closed position, loosen the two screws
through the access holes.
2. Insert a small stick into hole of cutter and
 turnthebladeuntilthenextcuttingposition
 isexposed(Positionswillbemarked1to8
on cutter blade).
3. Tighten screws.
