Clipper C1316SS - Page 34

34
C13xxx and C20xx Frame Common
Item Description
Req
Part No.
1 LIFT FRAME
1
238171
2
LIFT FRAME HOOK
1
238175
3
SCR 3/8-16 X 1 1/4 HEX HD CAP
23
8041051
4
WASHER 3/8 SPRING LOCK
23
8177012
5
WASHER 3/8 SAE
23
8172009
6 FRONT POINTER FRAME
1
238177
7 SCR 5/16-18 X 2 ½
1
8041034
8 WASHER 5/16 SAE
1
8172008
9 NUT 5/16-18 HEX LOCK
1
8160002
10
POINTER ROD
1
238168
11
NUT 3/8-16 HEX
1
8142003
12
SCR 3/8-16 X 1 1/2 HEX HD CAP
1
8041052
-NA- ROPE ¼”ODX16’-3/8”
1
238211
14
WRENCH OPEN END 1-1/4
1
238212
15
WRENCH OPEN END 1-1/2
1
238213
16
GUARD BELT
1
238135
17
SHAFT GUARD
1
238136
18
ENGINE BASE
1
238119
19
SCR 1/2-13 X 1 1/2 HEX HD CAP
4
8041096
20
WASHER 1/2 SPRING LOCK
4
8177014
21
WASHER 1/2 SAE
4
8172011
22
CONSOLE TOP WELD
1
238115
23 CONSOLE WELDMENT
1
238114
24
FRAME C20xx/C13xx/PC20xx
1
238101
25 CONSOLE TOP REAR COVER
1
238140
26 CONSOLE REAR COVER
1
238141
27 NUT 3/8-16 HEX LOCK
2
8162003
28 WHEEL 3” X 1” X 5/16”
1
238215
