Clipper C1316SS - Controls and Console Group

45
C13xx and C20xx Controls and Console Group
ITEM DESCRIPTION
Req
PART No.
1 HANDLE BAR
1
238120
2 HANDLE BAR GRIP
2
N1C0004
3 SCR 3/8-16 X 1 1/4 HEX HD CAP
4
8041051
4 WASHER 3/8 SAE ZN PLT
4
8172009
5 NUT 3/8-16 HEX LOCK
6
8162003
6 SCR 1/4-20 X 1 HEX HD CAP
5
8041006
7 WASHER 1/4 SPRING LOCK
5
8177010
8 WASHER 1/4 SAE
5
8172007
9
FUEL TANK
(20HP ONLY)
1
238130
10
THROTTLE CABLE
(INCLUDES CABLE AND CONTROL)
1
238228
11
SWITCH IGNITION 20HP HONDA
(20HP ONLY)
1
229196A
11
SWITCH IGNITION 13HP HONDA
(13HP MANUAL START ONLY)
1
227115
11
SWITCH IGNITION 13HP ES HONDA
(13HP ELECTRIC START ONLY)
1
229216A
12 TRANSMISSION CONTROL
1
238226
13 EMERGENCY KILL SWITCH
1
238229
14 NUT 1/4-20 HEX LOCK
1
8160001
15 SPRING 8"
1
238203
16 TRANSMISSION SPRING BAR
1
238204
17 ENGAGEMENT LEVER
1
238157
18 SCR 3/8-16 X 2 HEX HD CAP 8041054
19 TRANSMISSION ENGAGE LEVER
2
238156
20 SCR 3/8-16 X 1 1/2 HEX HD CAP
1
8041052
21 BALL KNOB
1
238202
22
BATTERY TRAY
(ELECTRIC START ONLY)
1
238160
23 WASHER 3/8 SPRING LOCK
6
8177012
24
BATTERY CB-16
(SOURCE LOCALLY)
1
-NA-
25
BATTERY MOUNT PAD
(ELECTRIC START ONLY)
1
238331
26
FUEL TANK GROMMET
(20HP ONLY)
1
N1C0016
27
FUEL TANK CAP 20HP ONLY
(WILL NOT FIT 13HP ENGINES)
1
238232
28
CHOKE CABLE
(20HP ONLY)
1
238209
29 TACHOMETER
1
232080
30 SCR No. 10-24 X 1 SOCKET HD
2
8042007
