C13xx and C20xx Raise Axle
ITEM DESCRIPTION
Req
PART No.
1 RAISE AXLE MOUNT
1
238134
2
REAR AXLE BUSHING
1
238129
3
REAR WHEEL SPACER
2
238124
4
WASHER 3/4 SAE
8
8172015
5
WHEEL 6 X 2 X 3/4 W/ROLLER BEARING
(REAR WHEEL SOLD EACH)
2
238005
6
WHEEL 5 X 2 X 3/4 W/ROLLER BEARING
(FRONT WHEEL SOLD EACH)
2
238004
7 RAISE AXLE WELDMENT
1
238126
8 SCR 3/8-16 X 2 1/2 HEX HD CAP
3
8041056
9
WASHER 3/8 SAE
1
8172009
10
NUT 3/8-16 HEX
12
8142003
11 NUT 3/8-16 HEX LOCK
1
8162003
12
SCR 3/8-16 X 1 1/4 HEX HD CAP
4
8041051
13
WASHER 3/8 SPRING LOCK
4
8177012
