Clipper C1316SS - Page 38

38
C13xxx and C20xx Transmission
ITEM DESCRIPTION Req PART No.
1 SPROCKET 35B12 X 17mm 1 229144
2 SCR 1/4-20 X 1/4 SET CUP 6 407035
3 ROLLER (1) 2 238150
4 BEARING FLANGE 3/4 B 2 210071
5 SPROCKET 35B48 X 34 B 1 238152
6 MASTER LINK 1 238145
7 CHAIN # 35 1 238146
8 KEY 3/16 X 2 3 9201086
9 TRANSMISSION JACKSHAFT 1 238155
10 SCR 3/8-16 X 1 1/4 HEX HD CAP 4 8041051
11 WASHER 3/8 SAE 18 8172009
12 NUT 3/8-16 HEX LOCK 11 8162003
13 TRANSMISSION MOUNT 1 238149
14 SCR 3/8-16 X 3 1/2 HEX HD CAP 4 8041060
15 SCR 1/2-13 X 1 1/2 HEX HD CAP 4 8041096
16 WASHER 1/2 SPRING LOCK 4 8176014
17 WASHER 1/2 SAE 4 8172011
18 TRANSMISSION M6 1 107744
19 # 3 WOODRUFF KEY 3
9203009
20 TRANSMISSION CONTROL LEVER 1 238154
21 WASHER 3/8 SPRING LOCK 1 8177012
22 NUT 3/8-16 HEX 3 8142003
23 PULLEY 4 O.D. X 17mm 1G 3VX 1 238151
24 WASHER 1/4 SAE 1 8172007
25 SCR 1/4-20 X 3/4 HEX HD CAP 1 8041007
26 IDLER ARM 1 238131
27 SCR 3/8-16 X 1 1/2 HEX HD CAP 1 8041052
28 PULLEY 3 O.D. X 7/8 1G 3VX 1 238006
29 BEARING 99R10 1 237408
30 SPRING 2 ½ 1 238221
31 PIN 1/8 X 1 1/2 COTTER 1 8197063
32 BELT 3VX425(1) FOR 20 HP ONLY 1 109799
33 BELT 3VX450(1) FOR 13 HP ONLY 1 109769
34 BUSHING SPACER 2 238236
