Clipper C1316SS - Page 41

41
C13xxx and C20xx Blade Shaft & Engine Group
ITEM DESCRIPTION
Req
PART No.
1 BLADE SHAFT
1
238179
2
TIGHT COLLAR RIGHT SIDE
(LEFT HAND THREADS)
1
227159
3
TIGHT COLLAR LEFT SIDE
(RIGHT HAND THREADS)
1
227190
4
LOOSE COLLAR OUTER FLANGE
(INCLUDES DRIVE PIN)
2
227247
5
NUT BLADE SHAFT 3/4-16 LH x 1” LONG
(OPERATOR”S RIGHT SIDE)
1
227156
6
NUT BLADE SHAFT 3/4-16 RH x 1” LONG
(OPERATOR”S LEFT SIDE)
1
227191
7 BEARING PIL BLK 1-1/4 2-B
2
106218
8
SCR 1/2-13 X 1 1/4 HEX HD CAP
4
8041095
9
WASHER 1/2 SPRING LOCK
4
8176014
10
WASHER 1/2 SAE
4
8172011
11 PULLEY 4.5OD X 1.25B 4G 3VX
1
238015
12
1/4-20 X 3/8 SOCKET SET SCREW
4
407036
13
PIN DRIVE (GROOVED) 3/8X1
2
227154
14
BELT 3VX355 (4) (SET OF 4)
1
238207
15
Pulley 3.15 OD x 1.00 ID 5G 3VX (All 13HP and 20HP
GX620QAF2 Saw Serial Numbers 07051016 to 07051032 Only)
1
238013
16
Pulley 3.15 OD x 1.125 ID 5G 3VX (20HP 16” & 20”
GX620TXF2 Saw Serial Number 07051033 and Higher)
1
238011
33
Pulley 2.65 OD x 1.125 ID 5G 3VX (20HP 24” GX62TXF2
Only Saw Serial Number 07051033 and Higher)
1
238012
17
KEY 1/4 X 2 ½
1
9201125
18 SCR 3/8-16 X 2 HEX HD CAP
4
8041054
19
WASHER 3/8 SAE
8
8172009
20 NUT 3/8-16 HEX LOCK
4
8162003
21
ENGINE 20 HP (GX620TXF2)
1
229182
22
ENGINE 13 HP ELECTRIC START (GX390UT1QAE2)
1
084044
23 ENGINE 13 HP MANUAL START (GX390K1QXC9)
1
123327
24 ENGINE BASE
1
238119
25 OIL DRAIN HOSE ASSY 13HP
1
238057
26 OIL DRAIN HOSE ASSY 20HP
1
238058
27 KEY 1/4 X 2-1/4 1
9201123
28 SCR 1/2-13 X 4 FULL THREAD HEX HEAD CAP 2
229133
29 NUT 1/2-13 JAM 2
8143005
30 SCR 1/2-13 x 1-1/2 HEX HEAD CAP 4
8041096
31 WASHER 1/2 SPRING LOCK 4
8176014
32 WASHER 1/2 SAE 4
8172011
-NA- MUFFLER 20HP HONDA 1
229183
