C13xx and C20xx Blade Guard and Water System Group
ITEM DESCRIPTION
Req
PART No.
1 HOSE SWIVEL
1
N1D0082
2 WATER VALVE 1/2"
1
N1C0021
3 HOSE BARB 1/2" x ½”MPT
1
9602012
4 HOSE CLAMP
2
N1C0113
5 SCR 1/4-20 X 1 HEX HD CAP
2
8041006
6 WASHER 1/4 SAE
2
8172007
7 FIT BARB HOSE 1/4MPTX1/2
2
9600014
8 “Y” FITTING x 1/4FPT
1
72286
9
BLADE GUARD 16”
(BLADE GUARD ONLY)
1
238144
10
BLADE GUARD 20”
(BLADE GUARD ONLY)
1
238142
11
BLADE GUARD 24”
(BLADE GUARD ONLY)
1
238143
12 TUBE 1/2ID X 3/4OD 48"LNG (USE 36")
1
0042521
13 GUARD LOCK
2
238225
14 SPRING GUARD LOCK
2
238224
15 PIN GUARD LOCK
2
238222
16 RING GUARD LOCK
2
238223
17 NUT 1/4-20 HEX LOCK
2
8160001
18
NOZZEL WATER (2)
(Set of Two (2) Nozzles)
1
82998
19 SPLASH GUARD (FLAP OR MUD FLAP) ONLY
1
238137
20 SCR ½-13 UNC x 4-1/2 HEX HEAD CAP
1
8041107
21
WASHER 1/2 SPRING LOCK
2
8176014
22
WASHER 1/2 SAE
2
8172011
