Clipper C1316SS - Page 47

47
C13xxx and C20xx Depth Adjustment Group
ITEM DESCRIPTION
Req
PART No.
1 DEPTH SCREW TUBE
1
238164
2 GREASE ZERK 1/8
1
238234
3 SCR 1/4-20 X 1/4 SET CUP
1
407035
4 NUT 3/4-10 HEX HEAD
1
238163
5 RAISE SCREW
1
238165
6 DEPTH STOP BUSHING
1
238166
7 BEARING FLANGE 3/4 B
1
210071
8 NUT 1/2-13 HEX HEAD
1
8143005
9 DEPTH STOP ROD 1/2-13 X 7"
1
238223
10 WASHER 1/2 SAE
1
8172011
11 DEPTH STOP HANDLE
1
N1C0078
12 NUT 1/2-13 HEX LOCK
1
8160005
13 HAND-WHEEL SPACER
1
238167
14 HAND-WHEEL
1
238169
15 WASHER 5/8 SAE
1
8172013
16 WASHER 5/8 SPRING LOCK
1
8177016
17 ACORN NUT 5/8-11
1
238235
18 SCR 3/8-16 X 1 1/2 HEX HD CAP
2
8041052
19 WASHER 3/8 SAE ZN PLT
4
8172009
20 KEY 3/16 X 1 1/4
1
9201080
21 WASHER 3/8 SPRING LOCK
4
8177012
22 SCR 3/8-16 X 2 1/2 HEX HD CAP
1
8041056
