C13xxx and C20xx Optional Water Tank Group
ITEM DESCRIPTION
Req PART
No.
-NA-
WATER TANK KIT
(INCLUDES: Items 1, and 3 to 10)
1
238001
1 WATER TANK W/CAP
1
83357
2
CAP FOR WATER TANK
1
82794
3
BRACKET FOR WATER TANK
1
238174
4
SCR 3/8-16 UNC x 1-1/4 HEX HEAD CAP
4
8041051
5 WASHER 3/8 SPRING LOCK
4
8177012
6 REDUCER FIT 3/4FGH x 1/2MPT
1
238065
7
COUPLER QUICK DETACH
(INCLUDES MALE & FEMALE QD COUPLERS)
2
238066
8 REDUCER FIT 3/4MGH x 1/2FPT
2
238067
9 LIFTING HOOK FOR WATER TANK C13xx/C20xx
1
238173
10 REDUCING BUSHING 1/2MPT X 1/4MPT
1
83218
NOTE: 238001 Water Tank Kit Includes: 83357 (Water Tank with Cap), 238174
(Bracket for Water Tank), 238173 (Lifting Hook for Water Tank), 238065
(Reducer Fitting 3/7 FGH x 1/2MPT), 238066 (Coupler Quick Detach Male &
Female Kit), 238067 (Reducer Fitting ¾ MGH x ½ FPT), 83218 (Reducing
Bushing ½ MPT x ¼ MPT), 8041051 (x4) ( Screw 3/8-16 x 1-1/4 Hex Head Cap),
8177012 (x4) (Washer 3/8 Spring Lock).
