3 - POSITIONING
3.1 PRELIMINARY INFORMATION
3.2 FUNCTIONAL SPACES
3.3 POSITIONING
Units are designed to be installed:
• INTERNAL
• in fixed positions.
Limit vibration transmission:
• use antivibration devices on unit bearing/supporting
points;
• install flexible joints on the hydraulic.
Installation standards:
• Safe accessible position;
• avoid flood-prone places;
• verify unit weight and bearing point capacity;
• verify that all bearing points are aligned and leveled;
Operate in compliance with safety regulations in force.
For detailed information (dimensions, weight, technical
characteristics etc.) please refer to the TECHNICAL
INFORMATION section.
Use single protection devices : gloves, glasses ecc.
During positioning consider these elements :
• technical spaces required for the machine and system
• place where the machine will be installed
• electrical connections
• water connections
• air / aeraulic ducts
Do not considerer these elements could decrease
performances and operational life of the unit.
Functional spaces are designed to:
• guarantee good unit operation
• Carry out maintenance operations
• protect authorized operators and exposed people
Respect all functional spaces indicated in the TECHNICAL
INFORMATION section.
Double all functional spaces if two or more unit are aligned.
