101
M0CZ00007-03
SYSTEM COMPONENT CONFIGURATION
Combining the terminal of reference with the master terminal in the
configuration
Component 1 :
DAY area, thermostat YES, terminal of reference NONE
Component 2 :
DAY area, thermostat YES, terminal of reference 1
Component 3 :
DAY area, thermostat YES, terminal of reference 1
Component 4 :
NIGHT area, thermostat YES, terminal of reference NONE
Component 5:
DAY area, thermostat NO, terminal of reference 4
DAY
NIGHT
Master terminal
