21
Installation
70M - 88M - 105M - 120M models
S1
S2
Morsettiere unità ESTERNA
segnale (BUS)
Cavo schermato
a 2 conduttori
dalle morsettiere
dell’unità INTERNA
L N
XT1
XT2
(1)L (2)L
230V~50Hz
PENL
alimentazione
OUTDOOR unit terminal blocks
power supplysignal (BUS)
from the INDOOR unit
terminal blocks
Shielded,
2-conductor
cable
Fig. 21
105T - 140T - 160T models
S1
S2
segnale (BUS)
400V~50Hz
alimentazione
a 2 conduttori
dalle morsettiere
PE NL1 L2 L3
L1
N (1)L (2)N
XT1 XT2
L2 L3
OUTDOOR unit terminal blocks
power supply signal (BUS)
from the INDOOR unit
terminal blocks
Shielded,
2-conductor
cable
Fig. 22
