Wiring

e Page 23 f

CAUTION

After conrmation of the above conditions, follow these guidelines when performing wiring:

• Always have an individual power circuit specically for the air conditioner. Always follow the

circuit diagram posted on the inside of the control cover.

•

• Check the specications for the power source.

• Conrm that electrical capacity is sucient.

• Conrm that the cable thickness is as specied in the power source specications.

• Always install an earth leakage circuit breaker in wet or moist areas.

Screws fastening the wiring in the casing of electrical ttings may come loose during

transporation. Because loose screws may cause wire burn-ou, check that the screws are tightly

fastened.

• The following can be caused by a drop in voltage: vibration of a magnetic switch, damaging

the contact point, broken fuses, and disturbance of normal functioning.

• Conrm that starting voltage is maintained at more than 90 percent of the rated voltage

marked on the name plate.

• Before accessing terminals, all supply circuits must be disconnected.

• Disconnection from a power supply must be incorporated into the xed wiring. It must have

an air gap contact separation of at least 3mm in each active (phase) conductors.

The qualied technician must use an approved circuit breaker or switch.

NOTE: To satisfy the EMC compulsory regulations, which are required by the international standard

CISPR 14-1:2005/A2:2011 in specic countries or districts ,please make sure you apply the

correct magnetic rings on your equipment according to the wiring diagram that adhere to

the your equipment .

Please contact your distributor or installer to get further information and purchase

magnetic rings, the supplier of magnetic ring is TDK（model ZCAT3035-1330） or similar .

Model E

Model C Model D

OPTIONAL

LPPUS REWOPY

1(A)

2(A)

3(A)

1(B)

2(B)

3(B)

1(C)

2(C)

3(C)

1(D)

2(D)

3(D)

1(E)

2(E)

3(E)

TO A

TO B

TO D

TO E

TO C

OPTIONAL

Model F

L(C)

N(C)

S(C)

L(D)

N(D)

S(D)

L(E)

N(E)

S(E)

TO D

TO E

TO C

L(A)

N(A)

S(A)

L(B)

N(B)

S(B)

TO A

TO B

OPTIONAL

LPPUS REWOP

OPTIONAL
