M0G140F7-01 06/11/07 pag 37
TECHNICAL DATA
SIZE 82 102 122 162 182 222 262 302
Cooling
Cooling capacity 1 kW 24,3 28,2 33,7 40 45,9 54,4 64,1 72,2
Comp. input power 1 kW 8,5 10 12,1 13,5 16 19,2 22,3 25,5
Total input power 2 kW 8,9 10,4 12,5 14,2 16,7 19,9 23,4 26,6
EER 1 2,73 2,72 2,71 2,81 2,74 2,73 2,74 2,71
ESEER 4,32 4,48 4.18 4,20 4,34 4.47 4,19 4,06
COMPRESSORS
Compressor type 3 SCROLL
No. of compressors Nr 2
Capacity control steps Std Nr 3 3 2 3 3 3 3 2
Refrigerant circuits Nr 1
Refrigerant charge (C1) l 3,61 3,72 3,54 5,76 5,76 6,65 7,39 8,28
INTERNAL EXCHANGER
Type of exchanger 4 PHE
No. Of exchangers Nr 1
Water flow-rate 1 l/s 1.2 1.3 1.6 1.9 2.2 2.6 3.1 3.4
Pressure drop kPa 48 47 41 43 43 38 40 42
Useful pump discharge head 1 kPa 132 126 120 104 88 148 139 131
EXTERNAL SECTION FANS
Fan type 5 AX
No. of fans Nr 2 2 2 4 4 4 6 6
Standard air-flow 1 l/s 2545 2538 2514 4933 4875 4778 7196 7145
Installed unit power kW 0,17 0,17 0,17 0,18 0,18 0,18 0,18 0,18
CONNECTIONS
Water fittings 1" 1/4 2"
HYDRAULIC CIRCUIT
Max water side pressure kPa 550
Safety valve calibration kPa 600
EXPANSION VESSEL
Expansion vessel capacity l 5
Maximum water side pressure 550
No. of expansion vessels Nr 1
POWER SUPPLY
Standard power supply V 400/3/50+N
NOISE LEVELS
Sound pressure level (1 m) dB(A) 60 60 60 61 62 62 64 64
DIMENSIONS
Length mm 1703 1703 1703 1932 1932 1932 2332 2332
Depth mm 675 675 675 1100 1100 1100 1100 1100
Height mm 1209 1209 1209 1417 1417 1417 1417 1417
Packing volume m
3
1,8 1,8 1,8 4 4 4 4,5 4,5
STANDARD UNIT WEIGHTS
Shipping weight kg 315 320 370 530 550 580 675 690
Operating weight kg 305 310 360 520 540 570 665 680
(1) data referred to the following conditions :
internal exchanger water = 12/7°C
external exchanger air intake 35°C
(2) Total absorbed power is given by the compressor absorbed power
+ fan absorbed power + auxiliary circuit absorbed power.
(3) SCROLL = scroll compressor
(4) PHE = plates
(5) AX = axial-flow fan
SETTING THE CUT-OUT DEVICES AND CONTROLS
On Off
High pressure switch (kPa) 4200 3300
Low pressure switch (kPa) 200 350 Max compressor starts per hour (n°) 10
Antifreeze protection (°C) 4 6,5 Safety discharge thermostat (°C) 120
FOULING CORRECTION FACTOR
INTERNAL EXCHANGER
m² °C/W F1 FK1
0.44 x 10^(-4) 1,00 1,00
0.88 x 10^(-4) 0,97 0,99
1.76 x 10^(-4) 0,94 0,98
The cooling performance values provided in the tables are based on the external exchanger having clean plates (fouling factor 1). For different
fouling factor values, multiply the performance by the coefficients shown in the table.
F1 = Cooling capacity correction factors FK1 = Compressors input power correction factors
