CLIVET WSAT-XEE 182 User Manual

M0G140F7-01 06/11/07 pag 41
Sizes 262-302
3
5
6
3
33
4
1
5
1
1
10
7
7
3
3
4
1
1
10
2
10
2
9 - 13
3
3
11
12
7
9 - 13
9 - 13
W1 W2
W4
W3
1417
21.5105021.5
1093
2332
4761612244
137
2
M N
O P
700 (14)
700 (15)
700 (14)
700 (15)
8
3
3
3
"G"
1050 21.521.5
244 1612 476
Size 262 302
M
mm 1105 1100
N
mm 1227 1232
O
mm 515 513
P
mm 585 587
Length mm 2332 2332
Depth mm 1100 1100
Height mm 1417 1417
W1
kg 166 173
W2
kg 99 103
W3
kg 146 151
W4
kg 109 113
Operating weight kg 520 540
Shipping weight kg 530 550
(1) COMPRESSOR
(2) FINNED EXCHANGER
(3) HELICAL FANS
(4) PLATE EXCHANGER
(5) EXCHANGER WATER RETURN
(6) EXCHANGER WATER SUPPLY
(7) PUMP
(8) POWER INPUT
(9) LIFTING HOLES
(10) ELECTRICAL PANEL
(11) MICROPROCESSOR KEYBOARD
(12) MAIN ISOLATOR SWITCH
(13) VIBRATION MOUNTS POSITION
(14) MINIMUM DIMENSION FOR A PROPER AIR FLOW TO THE
CONDENSER COIL
(15) MINIMUM DIMENSION FOR A SAFE PASSAGE.
(G) BARYCENTRE
VICTAULIC CONNECTION JOINT
