EXCELLENCE VERSION
Acoustic conguration: super-silenced (EN)
General technical data - Performance
Size 90.4 100.4 110.4 120.4 140.4 160.4 180.4 200.4 220.4 240.4
Cooling
Cooling capacity 1 [kW] 259 280 307 341 393 438 491 549 599 642
Compressor power input 1 [kW] 78 85 95 108 120 136 160 170 191 210
Total power input 2 [kW] 85,1 92,1 102,1 115 130 146 169 182 203 222
Partial recovery heating capacity 3 [kW] 67,4 73,0 80,4 89,8 103,0 115,0 130,0 144,0 158,0 170,0
Total recovery heating capacity 3 [kW] 319 349 385 433 491 552 626 697 763 837
EER 1 - 3,04 3,04 3,01 2,96 3,03 3,01 2,90 3,02 2,96 2,90
Water ow-rate (User Side) 1 [l/s] 12,4 13,4 14,7 16,3 18,8 20,9 23,5 26,2 28,6 30,7
Internal exchanger pressure drops 1 [kPa] 47 46 47 43 48 46 47 47 46 49
Cooling capacity (EN14511:2013) 4 [kW] 258 279 306 340 392 436 489 547 597 640
Total power input (EN14511:2013) 4 [kW] 86,0 93,1
103 116 131 147 171 184 205 224
EER (EN 14511:2013) 4 - 3,00 3,00 2,96 2,92 2,99 2,97 2,86 2,98 2,92 2,86
ESEER 4 - 4,27 4,33 4,38 4,26 4,33 4,28 4,42 4,32 4,35 4,35
Cooling capacity (AHRI 550/590) 5 [kW] 257 278 305 339 391 435 488 546 595 638
Total power input (AHRI 550/590) 5 [kW] 84,9 91,8 102 115 129 145 169 181 202 221
COP
R
5 - 3,03 3,03 3,00 2,95 3,02 3,00 2,89 3,01 2,95 2,89
IPLV 5 - 4,8 4,87 4,92 4,78 4,83 4,79 4,93 4,83 4,87 4,85
1. Data referred to the following conditions: internal exchanger water = 12/7 °C. Entering external exchanger air
temperature 35°C. Evaporator fouling factor = 0.44 x 10^(-4) m2 K/W
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome
the pressure drops for the circulation of the solution inside the exchangers
3. Option. Recovery exchanger water=40/45°C
4. Data compliant to Standard EN 14511:2013 referred to the following conditions: - Internal exchanger water
temperature = 12/7°C - Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water
temperature = 6,7 °C. Water ow-rate 0,043 l/s per kW. Entering external exchanger air temperature 35°C.
Evaporator fouling factor = 0.18 x 10^(-4) m
2
K/W
PREMIUM VERSION
Acoustic conguration: super-silenced (EN)
General technical data - Performance
Size 120.4 140.4 160.4 180.4 200.4 220.4 240.4
Cooling
Cooling capacity 1 [kW] 322 365 405 471 504 573 614
Compressor power input 1 [kW] 114 130 146 166 185 202 221
Total power input 2 [kW] 121 137 153 175 194 213 233
Partial recovery heating capacity 3 [kW] 89,8 102 114 131 144 160 174
Total recovery heating capacity 3 [kW] 419 480 548 622 685 758 824
EER 1 - 2,66 2,66 2,64 2,69 2,59 2,68 2,64
Water ow-rate (User Side) 1 [l/s] 15,4 17,4 19,4 22,5 24,1 27,4 29,3
Internal exchanger pressure drops 1 [kPa] 50,9 49,1 50,6 52,9 49,5 51,1 48,5
Cooling capacity (EN14511:2013) 4 [kW] 321 364 403 469 502 571 612
Total power input (EN14511:2013) 4 [kW] 122 138 155 177 196 216 235
EER (EN 14511:2013) 4 - 2,62 2,63 2,61 2,65 2,56 2,65 2,61
ESEER 4 - 4,07 4,04 4,03 4,04 4,01 4,07 4,05
Cooling capacity (AHRI 550/590) 5 [kW] 320 363
402 468 501 569 610
Total power input (AHRI 550/590) 5 [kW] 121 137 153 175 194 213 232
COP
R
5 - 2,65 2,65 2,64 2,68 2,59 2,68 2,63
IPLV 5 - 4,54 4,53 4,50 4,52 4,50 4,57 4,52
1. Data referred to the following conditions: internal exchanger water = 12/7 °C. Entering external exchanger air
temperature 35°C. Evaporator fouling factor = 0.44 x 10^(-4) m2 K/W
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome
the pressure drops for the circulation of the solution inside the exchangers
3. Option. Recovery exchanger water=40/45°C
4. Data compliant to Standard EN 14511:2013 referred to the following conditions: - Internal exchanger water
temperature = 12/7°C - Entering external exchanger air temperature = 35°C
5. Data compliant to Standard AHRI 550/590 referred to the following conditions: internal exchanger water
temperature = 6,7 °C. Water ow-rate 0,043 l/s per kW. Entering external exchanger air temperature 35°C.
Evaporator fouling factor = 0.18 x 10^(-4) m
2
K/W
WSAT-XSC3 90.4-240.4 5
