7 - CONTROL
42 Stato Valvola 2 c3 1=ON / 0=OFF
43 Stato Valvola 3 c3 1=ON / 0=OFF
44 Solenoide Liquido 1=ON / 0=OFF
45 Temp. batteria °C ( decimi )
46 Temp. IN recupero °C ( decimi )
47 Pressione condensazione bar
48 Pressione evaporazione bar
49 Stato Fan bar
50 Stato Sbrinamento 1=ON / 0=OFF
51 Tempo conteggio Sbrinamento sec
52 Ore comp. 1
53 Spunti comp. 1
54 Ore comp. 2
55 Spunti comp. 2
56 Ore comp. 3
57 Spunti comp. 3
58 Valvola recupero 1=ON / 0=OFF
59 Ritardo PREHP recupero sec
61 Ingressi digitali bit map di un byte
75 Potenza calcolata Daikin %
76 PEvapOp bar
77 Taspirazione °C(decimi)
78 Tscarico °C(decimi)
79 Apertura Valvola %
80 SuperHeat °C(decimi)
81 SuperHeatSPOperativo °C(decimi)
82 TempSaturaCondensazione °C(decimi)
Index GENERAL stata UM
0 Unit status
1=ON /
0=OFF
1 Unit mode
0=Cool, 1=
Heat
2 Actual set point °C (tenths)
3 Inlet temperature °C (tenths)
4 Outlet temperature °C (tenths)
5 Number of steps activated
6 Current step value (compensations) °C (tenths)
7 Step activation timer sec
8 Step activation dynamic TimeScan sec
9 CompExt °C (tenths)
10 CompWR °C (tenths)
11 CompCar °C (tenths)
12 CompSpunti °C (tenths)
13 CompDuty °C (tenths)
14 Outside temperature °C (tenths)
15 Outside humidity %
16 Free Cooling valve percentage %
17 Free Cooling flow percentage %
18 Free Cooling valve control
1=ON /
0=OFF
19 Pump 1 status
1=ON /
0=OFF
20 Pump 2 status
1=ON /
0=OFF
21 Water Reset %
22 Demand Limit %
60 Digital input
bit map of a
byte
68 Water flow analogic out
69 Pump module digital out
bit map of a
byte
71 BitMap connected nodes MS
bit map of a
byte
72 Hours pump 1 PMP
73 Hours pump 2 PMP
74 Hours pump 3 PMP
Index UNIT_1 – MOD COMP_1 stata UM
29 Compressor 1 1=ON / 0=OFF
30 Compressor 2 1=ON / 0=OFF
31 Compressor 3 1=ON / 0=OFF
32 Cp 1 timer status 1=ON / 0=OFF
33 Cp 2 timer status 1=ON / 0=OFF
34 Cp 3 timer status 1=ON / 0=OFF
35 Valve 1 c1 status 1=ON / 0=OFF
36 Valve 2 c1 status 1=ON / 0=OFF
37 Valve 3 c1 status 1=ON / 0=OFF
38 Valve 1 c2 status 1=ON / 0=OFF
39 Valve 2 c2 status 1=ON / 0=OFF
40 Valve 3 c2 status 1=ON / 0=OFF
41 Valve 1 c3 status 1=ON / 0=OFF
