1 - GENERAL
1.4 UNIT INDENTIFICATION
Serial number label
The serial number label is positioned on the unit and allows to
indentify all the unit features.
It has not to be removed for any reason.
It reports the regulations indications such as:
• machine type, exmple:
Series  WSH-XSC
Size  65D...
• serial number
12 characters  Axxxxxxxxxxx
• year of manufacture
• wiring diagram number
• electrical data
• manufacturer logo and address .
Serial number
It identifies uniquely each machine.
It identifies specific spare parts for the machine.
Assistance request
Note data from the serial number label and write them in the
chart on side, so you will find them easily when needed.
In case of intervention you have to provide data.
Serie
Size
Serial number
Year of manufacture
Wiring diagram
Size PE code W1 W2 W3 W4
65D PE960003 C6100024 C6100024 C6100024 C6100024
70D PE960003 C6100024 C6100024 C6100024 C6100024
75D PE960003 C6100024 C6100024 C6100024 C6100024
80D PE980002 C6100024 C6100026 C6100024 C6100026
85D PE980002 C6100024 C6100026 C6100024 C6100026
90D PE980002 C6100024 C6100026 C6100024 C6100026
100D PE980002 C6100024 C6100026 C6100024 C6100026
110D PE980002 C6100024 C6100026 C6100024 C6100026
115D PE980002 C6100024 C6100026 C6100024 C6100026
120D PE980002 C6100024 C6100026 C6100024 C6100026
135E PE960004 C6100026 C6100026 C6100026 C6100026
150F PE960004 C6100026 C6100026 C6100026 C6100026
165F PE980005 C6100026 C6100026 C6100028 C6100028
180F PE980005 C6100026 C6100026 C6100028 C6100028
ANTIVIBRATION DEVICES
It is recommended to put the unit on specific antivibration
devices .
Each support point of the unit sustains a different weight.
Therefore, each anti-vibration device is sized for a specific support
point, and can only be placed there.
The anti-vibration devices must therefore be placed in accordance
with the instructions provided with them and with the dimensional
drawings in which the support points are indicated by W1 , W2 ,
W3 etc .
On each anti-vibration device (if provided by CLIVET), its
identifying code is stamped, for example C6100100
Flexible joints are necessary on all the hydraulic/ aeraulic
connections (the joints are not supplied by Clivet)
