44/50: Installation and Operation Manual 11
31 Technical Specifications
Line inputs
Frequency Response
20Hz-20kHz ±0.5dB
Distortion <0.05% 20Hz -20kHz
Sensitivity 195mV (-12dBu) to 2.0V (+8dBu)
Input Gain Control 20dB range
Input Impedance
47kΩ
Headroom >20dB
Noise -90dB A weighted (0dB gain)
Equalisation
HF: ±10dB/10kHz LF: ±10dB/50Hz
Microphone Inputs
Frequency Response
100Hz / -3dB(filter) 20kHz ±0.5dB
Distortion <0.05% 20Hz-20kHz
Gain Range 0dB-60dB
Input Impedance
>2kΩ (balanced)
Common mode rejection >70dB 1kHz
Headroom >20dB
Noise
-128dB EIN 22Hz-22kHz (150Ω)
Equalisation
HF: ±10dB/5kHz LF: ±10dB/100Hz
Outputs
Auxiliary Outputs 775mV (0dBu) unbalanced (RCA phono sockets)
Speaker Outputs
50 watts rms/4Ω 35watts rms/8Ω via binding posts
100V line output
100 volts balanced – 250Ω min load (optional module)
70V line output
70 volts balanced – 125Ω min load (optional module)
Protection VI Limiting, DC Offset, Thermal & switch-on delay
Cooling Three speed DC fan
32 General Specifications
Power input
230V ±5% (115V ±5% available)
Fuse rating 230V – T3.15A 115V – T6.3A
Fuse type 20mm x 5mm class 3T 250V
Dimensions 482.60mm x 88.00mm(2U) x 300.00mm deep (+ con)
Weight 6.25kg net
