Cloud9 CloudHub - CloudHub Overview; CloudHub Front View; CloudHub Rear View; CloudHub Underside View

6 7
1. Install the power supply connector (see Diagram A)
into the Cloud9 CloudHub Power Supply Input.
Diagram A
POWER SUPPLY INSTALLATION
2. Install the Power Cord (see Diagram C) into the AC Power Supply (see Diagram B) for your Cloud9 CloudHub
and connect your Power Cord to the mains power socket.
Diagram B Diagram C
