Connections
Version 1 cmx® MSC 7460 Seite 9 von 16
4. Connections
4.1. Power supply
This set works on normal household AC-power.
Make sure the set voltage of unit matches your local voltage.
Insert the plug of the AC-cord into a wall outlet with AC-
power.
How to switch the unit “on”
To switch on the set, slide the function switch to “CD” or “RADIO”
as desired.
4.2. Speakers
Unwrap the speaker-cords of both speaker-boxes and insert
the left/right plugs into sockets in the rear of main unit
(see point 2 – location of controls / rear side).
Place the speaker-boxes as far apart as possible for best
sound effect.
4.3. Headphone
To connect the headphones or earphones insert the cable
into socket on the rear of main unit (see point 1 – location of
controls / rear side).
