CO/Tech IE40F-5A User Manual

ENGLISH
15
The flow of thepump is
too low.
Likely cause Solution
Check thethrottle lever. The throttle lever is
positionedwrong.
Put throttle lever to “Full throttle”.
Check thesuction hose. The suction hose may be
damaged, leaking, or too
long, or thediameter is
toosmall.
Check thesuction hose.
Leaking suction connection. Check that thegasket is fitted and
intact, tighten theconnection and
thehose clip.
The inlet filter is
partlyclogged.
Clean theinlet filter.
Check thepressure hose. The hose is damaged, too
long or thediameter is
toosmall.
Change thehose.
Measure thesuction/
pressure head.
The total head is almost at
maximum.
Change theplacement of
thepump and/or hoses.
10. Disposal
Follow local ordinances when disposing of this product. If you are unsure about how to dispose
of this product contact your municipality.
11. Specifications
Model IE40F-5A
Engine Air-cooled two-stroke engine
Cubic capacity 42.7 cc
Maximum engine power 1.5 hp
Fuel Mixture of petrol & oil 50:1 (2 %)
Tankage 1.2 litres
Spark plug TORCH: L7T
Champion: CJ6Y & CJ6RY
NGK: BPM6A & BPMR6A
Pump capacity 135 l/min
Maximum suction head 7 m
Maximum pressure head 30 m
Maximum water temp. 35 °C
Connection inlet/outlet 1″ external thread or hose nipple 25 mm (1″)
Idling speed 2500 rpm
Sound power level LwA 85 dB(A)
Sound pressure level LpA 70 dB(A)
Weight 8 kg
