4
ENGLISH
0
10
20
30
40
50
60
10
20
30
40
50
60
4
5 6
7
8
A
B
E
C D
F
G
9
10
1013
1014
1015
101
102
103
1011
1012
fig. 1
fig. 2
Product description
1. Mitre guide
2. Sanding disc
3. Work stop
4. Sanding belt
5. Belt tracking knob
6. Belt tension release lever
7. Side table locking knob
8. Dust extractor port
9. Belt tilt locking screw
10. Belt frame
11. Foot
12. Fastening hole
13. Power switch ON/OFF
14. Sanding disc guard
15. Side table
The bench sander is partly disassembled to protect it during transport.
Check that none of the following parts is missing before throwing the box away:
A. Belt and disc sander
B. Hex key
C. Side table locking knob
D. Work stop
E. Universal tool
F. Adjustable side table
G. Mitre guide
H. Instruction manual
