13. Specifications
■ CO2 & Temperature specification:
CO2 Specification
Measurement Range 0 - 50,000ppm (5%) display
Display Resolution
10ppm at 0~10,000ppm;
100ppm at 10,001~50,000ppM
Accuracy
+/-200ppm or +/-10% reading
Pressure Dependence Auto pressure compensation, built in barometer. (50 to 110 kPa)
Response Time CO2: <2min by 90%
CO2 AL1 (TWA ) 5000ppm fixed
CO2 AL2 5000, 1.0%, 1.5%, 2.0%, 2.5%, 3.0%. Default AL2= 1.5%.
CO2 AL3 2.0%,2.5%,3.0%,3.5%,4.0%. Default AL3= 3.0%
Sound Alarm 80db@10cm
Warm-Up Time <60 seconds at 22°C
Temperature Specification:
Temperature Range 0°C to 50°C (32°F to 122°F)
Display Resolution 0.1°C (0.1°F)
Display Options °C/°F
Accuracy ±1.5°C(±2.7°F) when CO2 level is below first alarm level
Response Time 20-30 minutes (case must equalize with environment)
Operating Conditions:
Temperature 0°C to 50°C ( 32°F to 122°F)
Humidity Range 0 ~ 95% RH non-condensing
Storage Conditions:
Storage Temperature -20°C to 60 °C (-4°F to 140°F)
■ Power Supply
Power
Supply
DC 9~32VDC (12~32VDC recommended), 2A.
AC adapter
Input: 100~240 VAC,50/60Hz, 0.6A
Output: 12VDC, 2000mA.
Battery Voltage
6VDC (5.4V~7.0V),
recommended capacity is 12AH
■ Relay output
Relay 1 Operates at CO2 TWA
Relay 2 Operates at Alarm 2 level for CO2
Relay 3 Operates at Alarm 3 level for CO2
The Peak current for all relays is less than 2A@30 VDC or 250 VAC, SPDT.
■ Weight and Dimension
SEU
Weight 1 lb
Dimensions (LxWxD) 6.69 x 4.96 x 2.73 inches
RDU
Weight 0.4 lb
Dimensions (LxWxD) 5.51 x 3.54 x 1.89 inches
