Important: Always read and follow operating instructions. • 7
Replace any damaged or missing safety decals. They are available from COATS, (800) 688-6359.
1 Tilting tower control pedal
2 Clockwise and counterclockwise clamping chuck (15) rotation control pedal
3 Wheel lifter (optional) control pedal
4 Inflation pedal
5 Button used to activate the “over-run” function of bead loosener disks (16 and 18)
6 Selector used to block the bead breaking carriage and to activate the “over-run” function (5)
7 Bead pressing arm control buttons (up/down)
8 Bead breaking carriage “forwards” movement button
9
Bead breaking carriage “backwards” movement button
10 Upper bead loosener disk lifting button
11 Upper bead loosener disk lowering button
12 Lower bead loosener disk lowering button
13 Lower bead loosener disk lifting button
14 Deflation button
15 Clamping chuck
16 Upper bead loosener disk
17 Lerevless mode control switch
18 Lower bead loosener disk
19 Operating arm control button
20 Leverless tire mounting/demounting system control switch
21 Upper bead loosener arm opening control
