ITEM:202701Q
(B1-B3)
COASTERFURNITURE.COM
ASSEMBLY INSTRUCTIONS
PAGE 12 OF 12
K
G
E
N
G
REMARK: AFTER COMPLETED THE DRAWER ALIGNMENT:
G
REMARK: IF THE DRAWER IS NOT ALIGNED, PLEASE DO THE BELOW ADJUSTMENT:
1) To align the drawer up or down
Action : Adjust the drawer frame (G) to up or down.
REMARK: 2) To align the drawer left or right.
Action : Adjust the drawer glide with rail (E) to left or right.
1) Adjust the leveler of drawer frame support (K) to touch the floor.
2) Fully tighten all the bolt from step 8, 9 & 10.
