800307
ITEM:
COASTERFURNITURE.COM
PAGE 2 OF 14
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIME
PARTS IDENTIFICATION
60 MINUTES
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
HARDWARE IDENTIFICATION
Z
NO DESCRIPTION FIGURE Q’TY
1 GLUE 40g
1PC
2
WOODEN DOWEL
Ø 8x30mm
72PCS
3
CAM BOLT
Ø 7x35.5mm
22PCS
NO DESCRIPTION FIGURE Q’TY
4
CAM LOCK
Ø 15x12mm
22PCS
5
BOLT
Ø 9.5x55mm
36PCS
6
STICKER
Ø 20mm
4PCS
A SIDE PANEL
12PCS
B
LOWER BACK
PANEL
1PC
C
LOWER DIVIDER
PANEL
2PCS
D BOTTOM PANEL
4PCS
E
UPPER DIVIDER
PANEL
6PCS
F
UPPER BACK
PANEL
3PCS
G CROSS PANEL
3PCS
H TOP PANEL
1PC
To Next Page
