Coaster 950170 - Hardware Identification

COASTERFURNITURE.COM
PAGE 3 OF 9
PARTS IDENTIFICATION
4PCSH
GLASS SHELF
565x250mm
ASSEMBLY INSTRUCTIONS
950170
ITEM:
HARDWARE IDENTIFICATION
4PCS
1
PLASTIC FEET
(∅44 x 18mm)
8PCS
2PCS
7
2PCS
8PCS
ALLEN BOLT-LARGE
(1/4" x 1-3/4")
WASHER
(1/4" x 16mm)
HANDLE
(40mm)
METAL CONTACT
(40mm)
2
8
3
4PCS
ADHESIVE
(38 x 42mm)
9
4PCS 4PCS
4PCS
HINGE
(40mm)
HINGE INSERT
(∅12 x 9mm)
SCREW
(∅8 x 22mm)
4
10
5
1PC
ALLEN KEY
(4mm)
11
4PCS
METAL WITH ADHESIVE
(38mm)
6
16PCS
SUCTION CUP
(∅20 x 28mm)
12
13
14
15
16
8PCS
SMALL BOLT
(∅7 x 6mm)
16PCS
BOLT
(∅8 x 30mm)
4PCS
PLASTIC MAGNET
(19mm)
4PCS
STICKER
(∅20mm)
