Cuddy Cabin
3-36
263 Owner’s Manual
Section 3
COCKPIT TONNEAU COVER -
OPTIONAL
Follow these directions for the cockpit tonneau
cover.
1. Unroll the cover and snap to the deck, starting
at the center of the windshield. Snap to the
forward outside edge of the windshield only.
2. Install tonneau support pole(s) to underside of
the cover (just in front of rear seat) with snap
and adjust pole to approximate height of
windshield. Some models have two support
poles. Make sure the poles are perpendicular to
the floor and adjust to “tent” the cover.
3. Pull elastic cords over discs on transom,
starting in the center and working outboard (you
may have to readjust the support poles for
proper fit).
4. Continue snapping up the sides.
5. The walk-thru doors may be closed if desired.
Do not use cockpit tonneau cover for extended
storage. It is not designed for storage, but can be
used for overnight storage or trailering.
BIMINI TOP - OPTIONAL
1. Remove the stainless adjustable arms from the
storage area.
2. Unfold the top and install the stainless
adjustable arms (tensioners) into the
quick-disconnect fittings on the deck, forward of
the windshield. Secure the forward arms to the
forward cross members with the pins.
3. Tighten the bimini by twisting the tensioners.
Do not trailer with the bimini top up. Store and
trailer the bimini top in the stowed position, in its
canvas boot.
BIMINI ENCLOSURE -
OPTIONAL
Your bimini is equipped with zippers to accept a
bimini enclosure. This enclosure is made of
Sunbrella canvas and isinglass. To install:
1. Start zipping the front, sides and aft curtain to
the zippers on the bimini top, but do not zip
completely.
2. Snap to the snaps on your deck and windshield
and then zip completely.
The supports can be adjusted for a better fit.
NOTICE: Always double check
snaps are secure.
COB_0089_A
COB_0138_A
COBALT
BOW TONNEAU
(BOW RIDERS ONLY)
COCKPIT
TONNEAU
