COBHAM Flexcomm I User Manual

FLEXCOMM II
C-5000 (Non-Digital)
Installation Manual
150-1355-000 Rev. K
CONFIDENTIAL AND PROPRIETARY TO COBHAM
Page 23
Table 1-12: Connectors Used (cont’d)
Item
Designat
or
Description
Wulfsberg P/N
Mil Spec P/N
Non RT-5000
Radio Install
Supplies
Kit
IN-210
Connector & Tray, Flexcomm™ I
149-0059-000
Connector
IN-210-1
Kit Includes: Mil-Circ, 61 Pin female,
Flexcomm™ I
149-0059-001
Tray
MT-210
Kit Includes: Mounting Tray,
Flexcomm™ I
300-2194-000
Adapter Cable
Single Harness to Dual Radio,
Flexcomm™ I
124-041326
Antennas
AT-50 / AT-51
Lo-Split RF
Connector
J511
N Type (Plug, straight) for use with
RG-142 coax)
N Type (Plug, 90) for use with
RG-142 coax)
129-049112-01
129-049113-01
Connector
J512
Mil-Circ, 10 Pin male
PN 129-217323-01
MS3126F-12-10S (SR)
AT-140
Lo-Split RF
Connector
N Type (Plug, Straight) for use with
RG-142 N Type (Plug, 90) for use
with RG-142
129-049112-01
129-049113-01
AT-400
Hi-Split RF
Connector
J401
N Type (Plug, straight) for use with
RG-393 coax)
N Type (Plug, 90 degree) for use
with RG-393 coax)
129-049115-01
129-049116-01
AT-150/AT-160
Hi-Split RF
Connector
J401
TNC (Plug, straight) for use with
RG-393 coax) TNC (Plug, 90
degree) for use with RG-393 coax)
129-041397-01
129-041398-01
Lo-Split RF
Connector
J402
N Type (Plug, straight) for use with
RG-142 coax)
N Type (Plug, 90 degree) for use
with RG-142 coax)
129-049112-01
129-049113-01
continues…...
