COBHAM Flexcomm I User Manual

FLEXCOMM II
C-5000 (Non-Digital)
Installation Manual
150-1355-000 Rev. K
CONFIDENTIAL AND PROPRIETARY TO COBHAM
Page 24
Table 1-12: Connectors Used (cont’d)
Item
Designator
Description
Wulfsberg P/N
Mil Spec P/N
AT-550 /
AT-560 /
AT-5000
Hi-Split RF
Connector
J401
TNC (Plug, straight) for use with
RG-393 coax TNC (Plug, 90
degree) for use with RG-393
coax
129-041397-01
129-041398-01
Lo-Split RF
Connector
J402
N Type (Plug, straight) for use
with RG-142 coax N Type (Plug,
90 degree) for use with RG-142
coax
129-049112-01
129-049113-01
Connector
J403
Mil-Circ, 10 Pin male
PN 129-217323-01
MS3126F-12-10S(SR)
Tuners / Logic Converters
FC-50 / FC-
550 / FC-
5000
Connector
J1
Mil-Circ, 19 Pin female
PN 129-217321-01
MS3126F-14-19S(SR)
Connector
J2
Mil-Circ, 3 Pin female
PN 129-217324-01
MS3126F-8-33S(SR)
Connector
J3
Mil-Circ, 10 Pin male
PN 129-214346-01
MS3126F1210P
Special Supplies
Cloning
Supplies
Kit
C-5000
Cloning Cable & RP_Win
Software Kit
149-041389-XX
Kit includes:
Software
RP_Win Software for Windows
404-041382
Cable
RP Cloning Cable
246-042755-01
continues…...
