COBHAM RT-5000 User Manual

FLEXCOMM II
C-5000 (Non-Digital)
Installation Manual
150-1355-000 Rev. K
CONFIDENTIAL AND PROPRIETARY TO COBHAM
Page 22
Table 1-12: Connectors Used
Item
Designat
or
Description
Wulfsberg P/N
Mil Spec P/N
Radio & Control Supplies
C-5000
System Interface
Connector
P500
D-Sub (62 Pin female, with
backshell and two male jackscrews)
PN 129-215344-01
Radio Option 1:
Serial Interface
Connector
P501,
P502
and/or
P503
D-Sub (37 Pin female, with
backshell and one each female and
male jackscrews) (For RT-5000
installations)
PN 129-217474-01
Radio Option 2:
Parallel Interface
Connector
P501,
P502
and/or
P503
D-Sub (62 Pin female, with
backshell and one each female and
male jackscrews) (For all
installations except RT-5000)
PN 129-215344-02
RT-5000
Interconnect
Harness
J101
Mil-Cir (55 Pin female)
PN 129-216657-01
MS3126F22-55S
Hi-Split RF
Connector
J102
TNC (Plug, straight) for use with
RG-393 coax TNC (Plug, 90 degree)
for use with RG-393 coax
129-041397-01
129-011398-01
Lo-Split RF
Connector
J103
N Type (Plug, straight) for use with
RG-142 coax N Type (Plug, 90
degree) for use with RG-142 coax
129-049112-01
129-049113-01
Tray Option 1
Mounting Tray, Vertical, RT-5000
300-316605
Tray Option 2
Mounting Tray, Horizontal, RT-5000
300-316835
Shock Mounts
(Recommended)
Shock Mounts, RT-5000, Vertical or
Horizontal Tray
246-044540-01
continues…...
