INSTALLATION MANUAL 4693-4698
15
J-20 Positive perimetric/odometer input: to be connected to the vehicle roof lamp only after the function has been activated
(see the “FUNCTIONS PROGRAMMING TABLES manual”). The input is 7 s delayed after the system arming.
J-21 Negative input to enter in programming procedure/to connect bonnet pushbutton: if connected to
ground the system will enter in the programming procedure for all applications not able to detect the original bonnet pushbutton. If the
siren is a wireless one this input must not be used for the bonnet pushbutton connections. For wired siren or loudspeaker this input
must be used for the connection of the bonnet pushbutton as indicated in the specifi c vehicle PLIP installation sheet.
J-22 Negative perimetric input: to be connected to the vehicle roof lamp or to the driver’s door wire when the signal il
separated from the one of the other doors. The input is 7 s delayed after the system arming.
J-23 Negative input for additional modules: to be used as a triggering input for the connection of compatible Cobra modules.
J-24 (see central door locking diagrams).
J-25 (see central door locking diagrams).
J-26 (see central door locking diagrams).
MAKE CONNECTIONS AS FOR ELECTRIC DIAGRAMS
