INSTALLATION MANUAL 4693-4698
5
5. - INSTALLATION PROCEDURE.
System’s component positioning.
As much as the components of the system will be placed in secure and diffi cult to access positions as higher the protection
level will be.
WARNING: each element must be positioned so that it does not interfere with moving parts.
Alarm unit.
It must be fi tted inside the vehicle far away from heating sources, paying attention to keep the main connector oriented down.
Siren.
It can be installed in the engine bay as inside the vehicle far away from heating sources paying attention to keep the
main connector oriented down.
Ultrasonic volumetric sensor.
The ultrasonic transducers must be fi xed to the top of the A pillars pointed towards the rear window or to the top of the
C pillars pointed towards the windscreen. Their orientation should be as much as possible parallel to the side windows.
Emergency LED/control button
It must be fi tted on the dashboard with its LED in a in sight position. The pushbutton should be easily accessible by the
driver.
Bonnet pushbutton.
The installation of the supplied pushbutton is required if the vehicle is not yet equipped with the original one. The specifi c
vehicle installation sheet supplies this info.
Antennas.
The RF antennas positioning (for both the main unit and the siren) is crucial for a proper system’s performance. They must
not be cut, wrapped, connected to any other cables or to the vehicle body and they must be kept separate from the main
wiring harness and as far as possible from metallic parts.
