Cobra Fortis 14L User Manual

23
1
2
2
Handle Position Adjustment
Fig. 42 Fig. 43 Fig. 44
The height of the handles may be adjusted to suit the operator.
At the lower section of the handle, the securing bolts should be loosened to adjust the angle of
the handles. The side cover should removed to access the two bolts on this side.
Once the required height is set, secure the bolts on each side. Refit the side cover with the two
bolts.
Lubrication and Maintenance
Warning: Switch off the engine and disconnect the spark plug connector before
making any adjustments of maintenance.
Lubrication Points
Fig. 45
Regular maintenance is essential to keep your lawnmower performing optimally and ensure it
operates safely. Routine lubrication of the following is required:
1. Height of cut adjuster knob – apply oil to the shaft. Fig. 45
2. The inner shaft of the front roller. Lubricate with oil. Fig. 45
