Page #26 background imageLoading...
Page #26 background image
26
9. FAULT DIAGNOSIS & REMEDY
Warning: Switch off the engine and disconnect the spark plug connector before
making any adjustments of maintenance.
10. TECHNICAL DATA
11.
WA
RR
AN
TY
This
prod
uct
is
warr
ante
d in
accordance with legal regulations for a 24 month period effective from the date of purchase by
Condition
Possible Cause
Remedy
Grass is not
cleanly cut or
grass is ripped.
The cylinder to bottom blade gap
is incorrect.
Check and adjust the gap. Check and
sharpen the cylinder if necessary.
The cut is not
consistent. Some
areas are not cut
correctly.
The cylinder to bottom blade gap
is not ‘on-cut’ across the whole
blade. The blade system is
damaged.
Check and adjust the gap. Check and
sharpen the cylinder if necessary.
Damaged see a Cobra dealer
Engine starting
problems.
Engine is flooded.
Spark plug lead not
connected. Spark plug is
dirty.
Leave for 10 15 minutes Reconnect
See engine maintenance manual
Engine stops
Engine does not stop
No petrol
Engine speed too low for
conditions.
Cutting cylinder obstructed
Refill petrol
Increase the throttle speed
Turn off engine and clear obstruction
Throttle cable not correctly
adjusted. Stop
engine by removing
spark plug lead and
refer to the engine maintenance manual.
Cutting cylinder does
not rotate
Cutting cylinder obstructed
Cylinder adjustment incorrect
Remove obstruction.
Adjust the cylinder bottom blade gap.
Power drive does
not work
Incorrect adjustment/cable
damaged
Adjust the drive cable so that the drive
operates.
Excessive vibration
or noise
Blade system or other mower part
damaged
Engine fault
Contact the local Cobra dealer
See engine maintenance manual
Model
Fortis 14L
Fortis 17B
Fortis 20B
Fortis 25B
Engine type
Loncin G200F
B&S XR550
B&S XR750
Self-Propelled
Yes
Engine Displacement
196cm³
127cm³
163cm³
Nominal Power
4.1kW
2.6kW
3.7kW
Blade Width
14in (36cm)
17in (43cm)
20in (51cm)
25in (63cm)
Rated Speed
3600/min
Fuel Tank Capacity
3.6L
1.9L
3L
Grass catcher capacity
55L
65L
75L
90L
Net Weight
74kg
83.6kg
89.2kg
104.8kg
Height adjustment:
6mm to 30mm with 6 Bladed Cartridge. As low as 3mm with the opt. 10 Blade
