Cobra MicroTalk - Controls and Indicators Overview

Controls and Indicators
A2
1. Antenna
2. Microphone/Speaker
Jack
3. On/Off Volume Switch
4.L LCD Display Panel
5.? Light/Max Range Button
6. Channel Select Button
7. Speaker
8 . Battery Compartment
9. Talk Button
10. Call Button
11. microTALK SNAP
Removeable Front
12. Lock Button
13. Mode Button
14. Charge Pads
7
9
5
1
2
8
1 4
4
1
3
9
1 2 1 3
5
1 1
6
1 0
3
6
