Cobra MT250C User Manual

3.Always be sure to turn off engine before performing any maintenance or checking
procedures
4.When sharpening, removing, or reattaching the blode proper tools and equipment to
prevent injury.
5.When replacing blade or any other parts or when replacing the oil or any lubricants,
always be sure to use
only products or products which have been certified by for use with the brush cutter.
5.SET UP
HANDLE
Fix Handle with four bolts
see figure 9
INSTALL GEARCASE
1. Loosen two clamp screws and remove one index screw
2.Push the pipe towards gearcase and rotate it by hand to
check that the mainshaft splines engage the powerhead.
3.Insert the pipe into gear case until it bottoms and align
the positioning holes on the pipe and gearcase. then
replace the index screw and tighten.
5. Fasten the pipe clamp securely with two clamp screws
see figure 10
23

Cobra MT250C Specifications

General

Brand	Cobra
Model	MT250C
Category	Trimmer
Language	English
