Adjusting the Throttle cable
1.Loosen the throttle cable nut at fan
cover as shown in figure 9.
figure
9
figure
10
figure
11
2.Adjust the throttle cable adjuster
nuts until you achieve a free play on
the throttle trigger of about 6mm.
See Figure 10.
When 6mm free play is achieved,
tighten the two 10mm throttle cable
nuts. When the throttle cable is
correctly adjusted, and the throttle
trigger is fully depressed (full
throttle), the throttle will contact the
stop on the throttle body. See Figure
11.
A dab of Never-Seez TM or equivalent
eases removal.
4.Replace the air cleaner cover.
7
