1. Brushing off dirt form the machine, check damage or slack of each part. If you
find out abnormalities, repair them for the next use.
2. Extract fuel from the tank, and loose the drain screw of the float cabin to extract
fuel, turn on the engine, and leave it running until it stops naturally.
3. Remove the spark plug and put in 1-2cc of 2-cycle oil in the engine. Draw the
starter rope 2-3 times, set the plug back, and stop it at the contraction position.
4. Apply snti-rust oil to the metal parts such as the throttle wire, put the cover on
the blade, and keep it indoor avoiding dampness.
8. MAINTENANCE
BLADE
Sharpen each culting edge and make sure the bottom
comer is rounded. (figure 24)
Do not cool the blade with water in case of using
grinder. It may cause cracks on blade.
GEAR CASE
Supply multi-purpose grease of every 25 hours of use.
Remove the cutter holders to arrange for old grease to
exit. (figure 27)
MAINTENANCE BEFORE STORAGE
26
